KS3+ Goal Unit 185 (Basketball)
KS3+ Goal Unit 185 (Basketball)
The KS3 Goal Unit 185 is a senior‑level steel multi‑sport goal engineered for secondary school and community use, supporting football, basketball and hockey for users aged 11+. Its integrated basketball backboard and ring set at 3050mm provide correct senior‑level shooting height, enabling appropriate skill development for KS3, KS4 and adult players. The frame delivers a substantial playing area, with an overall height of 3000mm, width of 3850mm and a deep 750mm goal space paired with a 2000mm goal height—ideal for structured matches, shooting practice and general playground sport.
Constructed from mild steel to BS EN 10210‑1:1994 and BS EN 10210‑2:1997 standards, the unit is fully galvanised for rust resistance and finished with a polyester powder coating to BS 6497, ensuring long‑term durability even in exposed outdoor environments. It includes child‑safe features that reduce finger‑trap risks, and the robust frame is vandal‑resistant, weatherproof and designed for heavy daily use. Optional cricket wickets and target panels can be added, and the structure is available in a wide range of RAL colours. The KS3 Goal Unit 185 is designed in accordance with BS EN 15312:2007 and BS EN 1270:2005 for compliance with free‑access multi‑sports safety requirements.
Galvanised
BSFG RAL 6001
BSFG RAL 7008
BSFG RAL 1013
BSFG RAL 7035
BSFG RAL 6027
BSFG RAL 2002
BSFG RAL 5015
BSFG RAL 5021
BSFG RAL 9005
BSFG RAL 3020
BSFG RAL 1023
BSFG RAL 2004
BSFG RAL 9006
BSFG RAL 1027
BSFG RAL 8017
BSFG RAL 7001
BSFG RAL 6018
BSFG RAL 6019
BSFG RAL 7039
BSFG RAL 8007
BSFG RAL 5024
BSFG RAL 9016
BSFG RAL 3005
BSFG RAL 4009
BSFG RAL 1028
BSFG RAL 5013
BSFG RAL 4005
BSFG RAL 7012
BSFG RAL 7016
| 2D DWG Available: | Yes |
|---|---|
| 3D Model Available (STEP/IFC): | Yes |
| Area of Application: | Outdoor |
| BIM Object Available: | No |
| BSFG RAL Colours Palette: | Galvanised, BSFG RAL 6001, BSFG RAL 7008, BSFG RAL 1013, BSFG RAL 7035, BSFG RAL 6027, BSFG RAL 2002, BSFG RAL 5015, BSFG RAL 5021, BSFG RAL 9005, BSFG RAL 3020, BSFG RAL 1023, BSFG RAL 2004, BSFG RAL 9006, BSFG RAL 1027, BSFG RAL 8017, BSFG RAL 7001, BSFG RAL 6018, BSFG RAL 6019, BSFG RAL 7039, BSFG RAL 8007, BSFG RAL 5024, BSFG RAL 9016, BSFG RAL 3005, BSFG RAL 4009, BSFG RAL 1028, BSFG RAL 5013, BSFG RAL 4005, BSFG RAL 7012, BSFG RAL 7016 |
| Basketball Hoop / Netball Ring Height: | 3050 mm, 3050 mm |
| Basketball or Netball: | Basketball |
| Country of Origin: | United Kingdom |
| Depth: | 750 mm |
| Designer: | Bailey Street Furniture Group |
| Finishing / Treatment: | Galvanised, Powder Coated |
| Goal Depth: | 750 mm |
| Goal Height: | 2000 mm |
| Goal Length: | 3850 mm |
| Goal Mouth Style: | Recess Goal |
| Height: | 3000 mm, 3000 mm |
| Key Stage: | Key Stage 3 (11 to 14 Years Old) |
| Length: | 3850 mm |
| Material: | Steel |
| Mounting Options: | Root Fixed |
| NBS Source Listed: | No |
| Play Values: | Competitive Play, Co-Operative Play, Gross Motor Skills, Stretching & Flexibility, Hand-eye Co-ordination, Communication Skills |
| Product Application: | Outdoor |
| Recyclable: | Yes |
| Side Panels: | No |
| Sports Activities: | Football |
| Upper Rebound Panel: | Yes |
| Upper Rebound Panel Height: | 1000 mm |
| Upper Rebound Panel Length: | 3850 mm |
| Warranty: | 1 Years |
Login
£5,923.00
Excl. VAT£7,107.60 Incl. VAT
Installation / fixing method
This Product can be customised with a range of optional fixtures. If you have any further bespoke requirements get in touch, our sales team will be happy to help.
Designed By:
Bailey Street Furniture Group
Bailey Street Furniture Group turns streets into social stages. With bold, sustainable designs—from benches to cycle hubs—they craft spaces where communities connect, play, and thrive, blending creativity with functionality for vibrant urban life.
FAQ
Overall height 3000mm, overall width 3850mm, goal height 2000mm and goal depth 750mm.
The ring is mounted at 3050mm.
It is designed for football, basketball and hockey and can be used individually or as a pair.
Yes. It is made from mild steel, fully galvanised and polyester powder coated for weatherproof, low‑maintenance and vandal‑resistant performance.
Yes, it is designed in accordance with BS EN 15312:2007 and BS EN 1270:2005.
